Overview
RMS-1000I High-Temp Insulation Material Resistivity Measurement System is engineered for ultra-high resistance characterization of insulating materials. As a professional resistivity test equipment manufacturer, we offer 100Ω to 10PΩ measurement capability with patented triple-ring electrode fixture. The system supports high-temperature, vacuum, and controlled atmosphere testing, making it ideal for aerospace sensors, ceramic insulators, polymer materials, and electronic packaging quality assurance.
Specifications
| Parameter | Value |
| Measurement Principle | Guarded three-ring electrode method |
| Main Measurement | Resistance, volume resistivity, leakage current vs temperature/time |
| Range | 100 Ω–10 PΩ resistivity solution |
| Temperature Control | Control accuracy up to ±0.5°C |
| Atmosphere | RT/high temperature; vacuum; flowing atmosphere |
| Notable Features | One-touch lift; built-in WiFi training; patented insulation fixture (2019204134342) |
| Temperature Range | RT-600°C / 1000°C |
| Temperature Control Accuracy | ±0.5°C |
| Temperature Control Method | PID precision control (3-stage) |
| Heating Rate | 0-10°C/min (typical 3°C/min) |
| Resistance Range | 100Ω ~ 10PΩ |
| Resistivity Range | 1000Ω.cm ~ 1PΩ.cm |
| Leakage Current | <0.5pA |
| Sample Specification | <25mm diameter, d<4mm |
| Measurement Method | Triple-ring electrode method |
| Electrode Material | Platinum (upper/lower) |
| Patent No. | 2019204134342 |
| Display | 10.1" color touchscreen |
| Data Interface | USB |
| Communication Interface | LAN port |
| Data Storage | TXT format |
| Dimensions (L×H×W) | 630×640×450mm |
| Weight | 42.5kg |
| Power Supply | 220V±10%, 50Hz, 2.6kW |
| Working Environment | 5°C to +40°C |
Applications
- RMS-1000I is essential for high-resistance measurement of ceramic insulators, polymer insulating materials, aerospace sensor components, electronic packaging materials, capacitor dielectrics, and transformer insulation systems. Widely used in aviation, aerospace, power electronics, and high-voltage equipment manufacturing industries.
More Details
Guarded Electrode Measurement
Three-ring electrode design reduces leakage current and improves stability.
High-Temperature Testing
Anti-oxidation furnace with ±0.5°C control accuracy; supports vacuum and flowing atmosphere tests.
